AD7606BSTZ Data Acquisition System
16-Bit 8-Channel True Synchronous Sampling – The Professional High-Density DAS ADC Hub Choice for Grid Monitoring & Multi-Phase Industrial Control.
// 8 Independent Analog Channels With 200 ksps Throughput Portfolio
The Synchronous Data Acquisition Advantage
The AD7606BSTZ represents a premier industry-leading benchmark for multi-channel data acquisition systems (DAS) requiring absolute phase alignment and high-density resolution. Engineered by Analog Devices, this single-chip solution unifies 8 independent analog input channels featuring clamp protection, programmable anti-aliasing filters, and a true 16-bit charge-redistribution SAR ADC matrix. Housed in a low-inductive 64-lead LQFP package layout, it executes continuous synchronous sampling loops up to 200 ksps, successfully preventing critical data skew hazards inside advanced smart grid monitoring and telemetry clusters.
- 8 Fully synchronous sampling channels entirely eliminating inter-channel phase delays
- Integrated input clamp protection tolerating aggressive voltage surges up to ±16.5V
- Flexible bus architecture backing high-speed Parallel, Serial SPI, and Byte read-out options
Key Performance Advantages
True Synchronous Sampling
Captures all 8 input channels at the exact same instant, securing critical phase coherence data for protective relays and three-phase power instrumentation.
Dual Bipolar Range Support
Features software/hardware selectable input ranges of ±10V and ±5V from a single +5V analog rail, omitting external operational amplifier scaling blocks.
1MΩ High Input Impedance
Maintains a high 1 Megohm analog input structure regardless of the sampling frequency, allowing direct connection to standard grid sensors and current transducers.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Analog Devices Inc. (ADI) |
| Part Number (MPN) | AD7606BSTZ |
| Product Family | Integrated 16-Bit Synchronous Data Acquisition System (DAS) Series |
| ADC Architecture | 16-Bit Successive Approximation Register (SAR) Core Matrix |
| Analog Input Channels | 8 Fully Independent Synchronous Single-Ended Inputs |
| Max Sampling Throughput | 200 ksps (Kilo-Samples Per Second) for All Channels Simultaneously |
| Input Voltage Ranges | True Bipolar Bounds: ±10 V and ±5 V (Single +5V Power Supply Node) |
| Digital Link Interfaces | High-Speed Parallel, Serial SPI, and Byte Interface Protocols |
| Package / Case Form | LQFP-64 / ST-64-2 Layout (Low Profile Quad Flatpack, 10mm x 10mm Body) |
| Temperature Window | Extended Industrial Performance Range (-40°C to +85°C) |
Versatile Instrumentation Applications
- Power Line Monitoring & Automation: Core telemetry acquisition for substation intelligent electronic devices (IEDs) and smart grids.
- Protective Relay Systems: Delivers instantaneous synchronous waveforms mapping to run zero-delay trip calculations securely.
- Multi-Phase Motor Controls: Real-time torque and current calculation arrays inside large-scale industrial motor drives.
- Data Acquisition Boards (DAQ): Standard premium hardware bridge linking complex high-density industrial sensors directly to microprocessors.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
