Broadcom Networking, Connectivity, and Isolation Solutions.
Connect the throughput, port count, protocol, latency, topology, isolation, package, lifecycle, and supply requirements of your system with a suitable Broadcom product direction—then source the exact part number with order-specific evidence and terms.
Search the Exact Broadcom Part.
Enter a Broadcom BCM, PEX, HCPL, ACPL, SAS, networking, storage, optical, or isolation ordering code.
Start With the Connection or Isolation Function.
Selecting by brand or headline speed alone can miss topology, protocol features, lane or port count, latency, package, power, software, safety, qualification, and lifecycle constraints.
Build a Data-Center or Enterprise Fabric
Define aggregate throughput, port speeds and counts, switching or routing role, buffering, telemetry, security, latency, power, cooling, host interface, software, and scale.
StrataXGS, StrataDNX, Ethernet controllers, network adapters, PHYs, and optical linksConnect Compute and Storage Devices
Review PCIe generation, lanes, ports, bifurcation, multi-host behavior, latency, retimer need, DMA and peer-to-peer traffic, form factor, firmware, and operating-system support.
PEX and ExpressFabric switches, retimers, SAS/SATA/RAID adapters, and controllersProtect Industrial Power and Control
Match gate-drive current, switching device, propagation delay, common-mode behavior, insulation, creepage, sensing accuracy, temperature, package, safety standard, and qualification.
HCPL and ACPL gate drivers, digital optocouplers, isolation amplifiers, and sensorsSupport a Released Infrastructure Platform
Confirm the complete part number, silicon or board revision, package, speed or protocol grade, firmware, driver, operating system, layout, optical or cable interface, and alternate authority.
Exact BCM, PEX, HCPL, ACPL, LSI/SAS, Brocade, and legacy-part reviewFind the Right Broadcom Product Family.
Use the portfolio family to narrow the architecture, then confirm the exact protocol, generation, throughput, lanes or ports, package, power, firmware, software, qualification, lifecycle, and supply condition.
Ethernet Switching
StrataXGS, StrataDNX, and integrated switching directions for data-center, enterprise, service-provider, campus, and embedded networks.
Review Switching DirectionEthernet PHYs and NICs
Copper and optical PHY ICs, PoE, controllers, network adapters, and SmartNIC directions selected by medium, speed, ports, and host interface.
View Ethernet PartsPCIe Switches and Retimers
PEX, PCI Express, and ExpressFabric directions for fan-out, multi-host, composable, accelerator, and storage interconnect architectures.
Review PCIe DirectionStorage Connectivity
SAS, SATA, RAID, HBA, controller, and storage-IC directions for servers, external arrays, backup, and high-availability platforms.
View Storage ProductsFibre Channel
Brocade SAN switching, directors, adapters, and Fibre Channel connectivity directions for resilient enterprise storage fabrics.
Explore SAN ApplicationsOptocouplers and Isolation
Digital optocouplers, gate drivers, IPM interfaces, isolation amplifiers, current sensors, and automotive or hermetic directions.
View Isolation PartsWireless and Broadband
Wi-Fi, Bluetooth, GNSS, RF front-end, set-top, cable, PON, DSL, and access-network directions for connected platforms.
Explore Access SystemsFiber-Optic Components
Lasers, detectors, VCSEL, PIN, optical components, transceivers, and industrial fiber products for short- and long-reach links.
Explore Optical LinksStart With Frequently Requested Broadcom Parts.
Use these parts as direct search entry points. Confirm the full suffix, generation, density, package, grade, lifecycle, controller or firmware context, and supply before purchasing.
GATE-DRIVE OPTOCOUPLERHCPL-3120-000E
Isolated gate-drive direction for IGBT and MOSFET power stages in industrial motor drives and conversion systems.
View Product
GIGABIT ETHERNET PHYBCM54616C0KFBG
10/100/1000BASE-T transceiver direction for enterprise, telecom, industrial, and embedded Ethernet ports.
View Product
ISOLATED GATE DRIVERACPL-W341-500E
Rail-to-rail isolated gate-drive direction for compact high-voltage inverter, converter, and motor-control designs.
View Product
PCIe GEN 3 SWITCHPEX8747-BA80FBCG
48-lane, 5-port PCI Express switch direction for multi-device, accelerator, graphics, and storage platforms.
View ProductMatch the Workload to a Broadcom Direction.
Choose the application and primary requirement. The result gives a starting product direction and the system details to confirm next.
Ethernet Switching and Connectivity
Begin with aggregate throughput, port speeds and counts, switching or routing features, buffering, latency, host interface, optical or copper medium, software, power, cooling, and scale.
Design Connectivity Around the Complete System.
Review compute and storage endpoints, data path, switches, PHYs, PCIe, optics, isolation, power, firmware, software, security, thermal design, qualification, and lifecycle as one platform.
AI and Scale-Out Fabrics
Align switching bandwidth, topology, endpoints, NIC or SmartNIC, RoCE, PCIe, optics, buffering, telemetry, security, power, cooling, and orchestration.
PCIe, SAS, and SAN Connectivity
Coordinate host lanes, switch fan-out, retimers, HBA or RAID role, SAS/SATA links, Fibre Channel, firmware, drivers, form factor, and redundancy.
Switching, Routing, and PHY Links
Define port rates and media, forwarding features, buffers, timing, PoE, management, software, signal integrity, cabling, optics, and service lifecycle.
Gate Drive and Current Sensing
Match IGBT or MOSFET, drive current, delay, common-mode behavior, insulation, sensing range, accuracy, creepage, safety standard, and temperature.
Vehicle Ethernet and Isolation
Review PHY or switch standard, topology, EMC, temperature, qualification, diagnostics, functional-safety context, isolation, package, and vehicle lifecycle.
Fiber, Access, and Wireless Links
Coordinate reach, wavelength, data rate, laser or detector, connector, optical budget, signal conditioning, thermal design, qualification, and module integration.
Compare Broadcom Connectivity Paths.
Use the system role as a starting point. Final selection depends on topology, protocol, endpoints, electrical and thermal limits, software, qualification, lifecycle, and the exact orderable device.
| Direction | Best Starting Point | Confirm Before Selection | Typical System Role |
|---|---|---|---|
| Ethernet Switch | Many endpoints and packet forwarding | Aggregate bandwidth, ports, buffers, features, latency, software, power | Data center, enterprise, campus, service provider |
| Ethernet PHY / NIC | Host or MAC to copper or optical link | Speed, medium, ports, host interface, offloads, signal integrity, drivers | Server, storage, industrial, automotive, edge |
| PCIe Switch / Retimer | Device fan-out and high-speed interconnect | Generation, lanes, ports, topology, latency, multi-host, firmware | Accelerator, server, composable, storage systems |
| Storage Connectivity | SAS, SATA, RAID, HBA, or SAN access | Protocol, ports, queue workload, RAID role, firmware, driver, form factor | Server, external array, backup, enterprise storage |
| Optocoupler / Isolation | Galvanic isolation, gate drive, or sensing | Drive, delay, CMR, insulation, accuracy, package, temperature, safety | Motor, inverter, charger, PLC, automotive power |
| Optical / Broadband | Fiber, access, or wireless physical link | Rate, reach, wavelength, optical budget, package, thermal, qualification | Data center, telecom, FTTx, broadband, industrial |
Turn the System Need Into an Orderable Part.
A general product family or link speed is not enough. Confirm the complete ordering code and the system, quality, commercial, and delivery conditions that define an acceptable supply.
Full part number, manufacturer, product family, protocol generation, package or board, and revision context.
Interfaces, lanes or ports, topology, host support, firmware, driver, operating system, optics or cable, and qualification.
Throughput, latency, traffic or switching features, isolation or sensing target, power, temperature, and lifecycle.
Quantity, required date, destination, source basis, condition, evidence, commercial terms, and approved alternatives.
Browse Broadcom Connectivity and Isolation Parts.
Filter representative Ethernet, PCIe and storage-connectivity, and optocoupler products. Search above when you already have an exact ordering code.
HCPL-3120-000E
Gate-drive optocoupler direction for isolated IGBT or MOSFET drive. Confirm output current, delay, CMR, insulation, package, temperature, safety, and lifecycle.
View HCPL-3120-000EBCM54616C0KFBG
10/100/1000BASE-T PHY direction. Confirm MAC interface, package, clocking, magnetics, cable, power, temperature, software, revision, and lifecycle.
View BCM54616C0KFBGACPL-W341-500E
Isolated gate-driver direction for inverter and converter stages. Confirm drive current, rail-to-rail behavior, delay, CMR, package, insulation, temperature, and qualification.
View ACPL-W341-500EPEX8747-BA80FBCG
48-lane, 5-port PCIe Gen 3 switch direction. Confirm lane topology, upstream and downstream ports, bifurcation, multi-host behavior, firmware, package, and lifecycle.
View PEX8747-BA80FBCG
BCM54612EB1KMLG
Single-port Gigabit Ethernet PHY direction. Confirm MAC interface, package, power, clocking, magnetics, signal integrity, temperature, revision, and software support.
View BCM54612EB1KMLG
HCPL-4503-000E
High-speed optocoupler direction for isolated signal interfaces. Confirm data rate, delay, CMR, input and output conditions, package, insulation, temperature, and lifecycle.
View HCPL-4503-000E
SAS9300-8I
Eight-port 12Gb/s SAS HBA direction. Confirm server slot, PCIe support, internal connectors and cabling, drive topology, firmware, driver, operating system, and workload.
View SAS9300-8I
ACPL-790B-000E
Precision isolation-amplifier direction for current and voltage sensing. Confirm input range, gain and offset error, bandwidth, CMR, insulation, package, and temperature.
View ACPL-790B-000E
ORDER-SPECIFIC REVIEWReview the Exact Part and Evidence Before Shipment.
YURUNOX reviews the quoted Broadcom component against the complete part number, package and grade, lifecycle, source basis, quantity, commercial terms, and agreed evidence.
From Broadcom Part Number to Purchase Approval.
A complete RFQ makes the system, revision, software, lifecycle, quality, commercial, and delivery expectations visible before the order moves forward.
BCM54616C0KFBG for a Released Ethernet Board
The buyer needs the exact Gigabit Ethernet PHY used by a validated platform. Any alternative must be reviewed against MAC interface, package and pinout, clocking, magnetics, power, timing, temperature, software, layout, and engineering authority.
Align the Platform
Confirm application, host or controller, full part number, board and software baseline, quantity, date, and alternate authority.
Review the Supply
Record source basis, offered quantity, condition, packing, available date or lot information, price basis, validity, and exceptions.
Agree the Evidence
Define label, packaging, visual, microscopic, marking, X-ray, electrical, documentation, or other requirements when suitable and agreed.
Approve the Release
Review evidence, exceptions, terms, shipping documents, protective packing, carrier handoff, destination, and tracking.
Broadcom Component Sourcing FAQ.
Prepare a clearer part search, design-in request, production order, shortage review, legacy-platform need, or BOM quotation.
What information should I send for a Broadcom RFQ?
Send the complete part number, application, host or controller, board or platform revision, quantity, required date, destination, approved alternatives, qualification needs, and requested evidence. For new selection work, add protocol, throughput, lanes or ports, package, power, software, and lifecycle targets.
Can YURUNOX help when I only know the system requirement?
Yes. Start with endpoints, topology, protocol, link rate, lanes or ports, switching or isolation function, host interface, package, power, thermal, software, qualification, production forecast, and lifecycle. YURUNOX can help organize a suitable Broadcom product direction for engineering review.
What must be checked before replacing an Ethernet PHY?
Compare supported standards, MAC interface, speed, package and pinout, clocking, magnetics, power rails, strap options, management interface, signal integrity, temperature, driver or software dependencies, revision, lifecycle, and validation authority.
How do I choose between a PCIe switch and retimer?
A switch creates multiple independently managed PCIe paths and may support fan-out or multi-host features. A retimer restores signal quality without creating a new switching hierarchy. Review generation, lanes, ports, reach, topology, latency, firmware, package, and validation plan.
Can you review Broadcom optocouplers for power applications?
Yes. Provide the switching device, bus voltage, gate-drive current, frequency, delay and dead-time target, common-mode environment, insulation and creepage requirements, sensing range if applicable, package, temperature, qualification, and safety standards.
Can you source older Broadcom BCM, PEX, HCPL, ACPL, or LSI parts?
YURUNOX can review active, constrained, EOL, and hard-to-find requests. Availability, source basis, condition, packing, date or lot information, lifecycle status, evidence, terms, and alternatives are confirmed for the actual offer rather than assumed.
How is part authenticity or condition reviewed?
The review can align the quoted identity, source basis, labels, packaging, condition, moisture protection, visual and microscopic observations, markings, available records, and additional testing when suitable and agreed. The scope depends on the actual order and risk.
Can I submit a mixed networking and isolation BOM?
Yes. Include one row per complete part number with quantity, target date, destination, approved alternatives, lifecycle constraints, and evidence requirements. Add host, board, firmware, driver, optical, cable, isolation, or qualification context where substitution risk is important.
Send Your Broadcom Part Number, BOM, or System Requirement.
Include the application, endpoints, full part number or preferred family, protocol, throughput, lanes or ports, package or board, firmware and software, quantity, target date, destination, alternatives, and evidence requirements.
