ADV7623BSTZ HDMI Transceiver IC
4-Input Receiver meets 1-Output Transmitter Core – The Professional HDMI Audio/Video Transceiver Choice for Display Systems & Media Matrix Gateways.
// Advanced 4:1 HDMI Switching Framework Portfolio
The High-Definition Video Routing Advantage
The ADV7623BSTZ represents a flagship solution for high-density HDMI signal distribution and switching. Engineered by Analog Devices (ADI) to meet strict digital content compliance guidelines, this transceiver features an integrated 4-input multiplexer paired with a single-output transmitter link. It streamlines media designs by incorporating hardware-driven HDCP decryption/encryption, on-chip Consumer Electronics Control (CEC), and highly versatile digital audio extraction matrices to deliver pure signal integrity in noise-heavy visual engineering systems.
- 4-Input, 1-Output HDMI transceiver with fast input channel toggling
- Integrated digital audio extraction supporting flexible I2S and S/PDIF formats
- On-chip hardware HDCP Keys backing dynamic repeater topology control
Key Performance Advantages
Crystal Clear 1080p
Supports high-definition standard display formats up to 1080p, delivering deep color depths and robust refresh metrics without video dropouts or signal loss.
Advanced Audio Extraction
Decouples high-fidelity digital audio nodes straight from the HDMI stream, outputting clean multi-channel links to localized DACs or amplification rails.
Full HDCP Compliance
Houses a dedicated internal HDCP cryptographic processing block, maintaining seamless handshakes across dense high-definition AV repeater loops.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Analog Devices, Inc. (ADI) |
| Part Number (MPN) | ADV7623BSTZ |
| Device Function | High-Performance 4:1 HDMI Transceiver with Audio Extraction |
| HDMI Configuration | 4 Inputs / 1 Output Multiplexed Architecture |
| Resolution Support | Up to 1080p, 3D Video Formats, and Deep Color Processing |
| Audio Support Nodes | 8-Channel I2S Outputs, S/PDIF Output, SACD / DSD Data Streams |
| Content Protection | Integrated HDCP Decryption/Encryption Key Engines |
| Package / Case | LQFP-144 / STZ Variant (Low-Profile Quad Flat Package) |
| Control Protocols | On-Chip Consumer Electronics Control (CEC) Master Subsystem |
| Operating Temperature | Standard Industrial Grade Specification Compliance (-40°C to +85°C) |
Versatile Multimedia Applications
- Home Theater AV Receivers: Central media hub handling input consolidation and master audio extraction pipelines.
- Automotive Infotainment: Multi-display distribution panels managing rear-seat screens and main console feeds.
- Digital Video Matrix Routers: High-reliability switching frameworks inside broadcasting studios and meeting rooms.
- Industrial Displays: Stabilizes digital video transmissions against severe factory electromagnetic noise.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
