FF450R12ME4 Dual IGBT Module
1200V Blocking Voltage meets 450A Current Collector – The Professional EconoDUAL™ 3 Module Choice for High-Power Inverters.
The High-Power Density Switching Advantage
The FF450R12ME4 represents a premier flagship modular solution for large-scale, high-voltage switching grids demanding absolute thermal control and massive collector current stability. Engineered by Infineon utilizing their patented Trenchstop™ IGBT4 matrix core, this dual-channel half-bridge module cuts down static conduction loss matrices flawlessly. Housed in an industry-standard EconoDUAL™ 3 baseline footprint layout, it secures pure, deterministic power telemetry loops and eliminates high-current electrical saturation hazards.
- 1200V Rugged blocking threshold handling voltage fluctuations inside heavy grids safely
- Integrated NTC thermistor sensor executing continuous localized temperature reporting
- Optimized low-inductance baseplate design layout dropping systemic switching noise limits
Key Performance Advantages
450A Dynamic Collector
Delivers continuous 450 Amp power conduction performance, keeping thermal dissipation envelopes highly optimized under constant industrial load stresses.
Trenchstop™ IGBT4 Core
Features an advanced trench-gate structure that establishes an incredibly low VCE(sat) saturation rating, boosting overall system energy conversion efficiency indicators.
EconoDUAL™ 3 Form
Housed in a globally standard mechanical outline frame with robust press-fit terminal pin routing configurations, ensuring dependable structural busbar scaling.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Infineon Technologies (International Rectifier) |
| Part Number (MPN) | FF450R12ME4 |
| Product Category | High-Power Dual Transistor Half-Bridge IGBT Modules |
| Max Blocking Voltage | 1200 V Maximum Collector-Emitter Voltage Breakdown Bound |
| Continuous DC Collector | 450 A Sourcing Current Rating (at TC = 100°C Terminal Condition) |
| IGBT Silicon Technology | Advanced Trenchstop™ IGBT4 with Emcon 4 Diode Matrix Array |
| Saturation Voltage | Typical 1.75V VCE(sat) Conduction Barrier Limit |
| Thermal Protection | Integrated Internal NTC Temperature Resistor Component |
| Package / Case Form | EconoDUAL™ 3 Base (Standard Copper Baseplate Surface Mount Housing) |
| Max Junction Temp | Extended Operation Performance Window Up to +150°C [175°C Max Switching] |
