Intel Core i7-6820EQ Processor
3.50 GHz Turbo Frequency meets 8MB High-Speed Cache – The Industrial-Grade Intel Embedded Quad-Core Silicon Choice for Rugged Military, Advanced Medical Imaging, and Heavy-Duty Edge Servers.
// Intel HD Graphics 530 Matrix vPro & ECC Memory Link Support 1440-Pin BGA
The Absolute High-Throughput Critical Compute Advantage
The i7-6820EQ represents a premier professional 1440-pin ball grid array (BGA) packaged 64-bit multi-core application microprocessor module engineered for space-constrained, high-throughput hardware architectures demanding absolute execution efficiency, intensive mathematical calculation processing, and extended life-cycle availability. Built on Intel’s legendary Skylake 14nm silicon architecture operating up to a deterministic 3.50 GHz turbo speed node, this quad-core, eight-thread framework processes heavy sensory automation datasets and automated visualization tasks flawlessly without thermal throttling risks or core execution lagging hazards. Supporting advanced ECC memory buffers and vPro remote telemetry management, it secures pure, deterministic processing routing loops and completely cuts off rugged computational bottlenecks.
- High-performance Quad-Core, 8-Thread execution framework running cleanly up to 3.50 GHz frequency nodes
- Massive built-in Intel Smart Cache structure delivering 8 Megabytes of unified high-speed memory space safely
- Elite graphics and media engine embedding Intel® HD Graphics 530 for real-time 4K rendering profiles smoothly
Key Performance Advantages
4 Cores / 8 Threads Power
Unlocks parallel processing capability, executing complex embedded Linux kernels and concurrent multi-sensor analytics pipelines cleanly without algorithmic latency bottlenecks.
ECC & vPro Security
Corrects single-bit data corruptions natively and opens stable out-of-band remote tracking management, safeguarding critical server systems against fatal runtime bugs safely.
Rugged BGA1440 Design
Deploys direct solder down ball architecture, neutralizing mechanical looseness risks from extreme vibrations or vehicular impacts smoothly.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Intel® Corporation (Premium Factory Sealed Sourcing) |
| Part Number (MPN) | I7-6820EQ / CL8066202194635 (Intel® Core™ Embedded Series) |
| Core Configuration | 4 Cores / 8 Threads Active Multithreading Processing Matrix |
| Clock Frequency Nodes | 2.80 GHz Base Clock / 3.50 GHz Max Turbo Velocity Peak |
| Smart Cache Memory | 8 Megabytes (8MB Intel® Smart Cache Allocation Layer) |
| Thermal Design Power | 45 Watts TDP (Configurable TDP-down options to 35W) |
| Memory Support Spec | DDR4-2133, LPDDR3-1866, DDR3L-1600 (Up to 64GB with ECC Support) |
| Integrated Graphics Engine | Intel® HD Graphics 530 (350MHz Base / 1.00GHz Dynamic Burst) |
| Expansion Bus Options | PCI Express* v3.0 (Configurable x16, x8, x4 Lane Distributions) |
| Package / Case Form | BGA1440 package (Direct-Solder 37.5mm x 27.5mm Grid Form Factor) |
Versatile High-Throughput Processing Applications
- Military & Defense Computing: Primary chip architecture driving secure radar signal concentrators and armored vehicle command terminals safely.
- Advanced Medical Diagnostics: Delivers deterministic data processing paths needed for real-time 3D ultrasound or MRI voxel mapping smoothly.
- Rugged Industrial PC Servers: Handles demanding factory automation datasets, high-load vision inspection, and SCADA control rooms cleanly.
- Transportation & Aerospace: Optimizes operational stability inside airborne computing instrumentation and train telemetry frameworks.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
