IMX179 CMOS Image Sensor
8.08 Megapixel Resolution meets MIPI CSI-2 Interface – The Professional Exmor R Back-Illuminated CMOS Choice for Cost-Effective Mobile and Embedded Machine Vision Frameworks.
// Back-Illuminated Pixel Matrix 10-Bit RAW Data Stream Bare Die Portfolio
The High-Speed Back-Illuminated Imaging Advantage
The IMX179 represents a premier professional 1/3.2-inch 8.08 Megapixel CMOS active pixel type digital image sensor solution engineered for space-constrained, high-throughput hardware architectures demanding absolute optical signal processing efficiency and fast frame rate transmission profiles. Built on Sony’s legendary Exmor R back-illuminated silicon framework, this module processes high-fidelity visual capture streams flawlessly without thermal pixel noise hazards or clock transmission barriers. Operating through high-speed MIPI CSI-2 serial data lanes, it secures pure, deterministic digital image routing loops and completely cuts off hardware synchronization delays.
- High-resolution 8.08MP active matrix grid (3264 x 2448 effective pixel count nodes)
- Advanced 2-lane MIPI CSI-2 interface output delivering raw 10-bit/8-bit data streams safely
- Incredible fluid frame rates supporting up to 30 frames per second under full resolution cleanly
Key Performance Advantages
Real-Time 30fps Capture
Captures full-resolution 8.08MP at 30fps, and high-definition 1080p/720p tracking streams smoothly without motion blur or latency bottlenecks.
Exmor R Sensitivity
Leverages a back-illuminated pixel structure to drastically increase photon gathering, reducing noise artifacts under dim illumination safely.
Ultra-Compact Layout
Designed as a premium raw silicon die system, integrating internal timing controllers and PLL units to maximize layout spatial savings smoothly.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Sony Semiconductor Solutions Corporation (Premium Sealed Allocation) |
| Part Number (MPN) | IMX179 (Exmor R Sensor Family Matrix) |
| Optical Format Size | 1/3.2-inch Active Diagonal Area Layout |
| Resolution Density | 8.08 Megapixels (3264 x 2448 Effective Pixel Matrix Grid) |
| Pixel Size Dimensions | 1.4 µm × 1.4 µm Fine Pixel Pitch Geometry |
| Data Interface Bus | MIPI CSI-2 Serial Link Interface (Configurable 2-Lane Mode) |
| Output Format Modes | 10-bit Raw Bayer / 8-bit Raw Bayer Digital Stream Output |
| Control Interface | I2C Compliant Standard Serial Control Bus Link |
| Supply Voltages Nominal | Analog: 2.8V / Digital Core: 1.2V / Interface I/O: 1.8V Tri-Rail Layout |
| Component Package | Bare Silicon Die package (with Micro-Lens and Color Filter Arrays Integrated) |
Versatile Embedded Vision Applications
- Mobile Devices & Tablets: Highly integrated sensor driving flagship front-facing or cost-effective main camera solutions safely.
- Machine Vision Edge Hubs: Delivers deterministic object recognition, document scanning, and automated industrial inspection smoothly.
- Drones & Smart Robotics: Handles demanding spatial navigation, high-resolution optical flow, and localized video capture loops cleanly.
- Biometric Access Terminals: Optimizes computational facial detection boundaries inside low-power camera installations and secure smart gates.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
