IMX290LQR CMOS Image Sensor
STARVIS Starlight Low-Light Sensitivity meets High-Speed Performance – The Professional 2.13MP Back-Illuminated CMOS Choice for Intelligent Security Surveillance and Industrial Machine Vision Systems.
// High-Sensitivity STARVIS Architecture 10-Bit/12-Bit RAW Data Stream 120fps Portfolio
The Absolute Starlight Low-Light Imaging Advantage
The IMX290LQR represents a premier professional 1/2.8-inch 2.13 Megapixel CMOS active pixel type digital image sensor solution engineered for space-constrained, high-throughput hardware architectures demanding absolute optical signal processing efficiency and elite low-light sensitivity. Built on Sony’s legendary STARVIS back-illuminated pixel technology framework, this module processes high-fidelity visual capture streams flawlessly under near-infrared or extreme low illumination without thermal pixel noise hazards or clock transmission barriers. Operating through high-speed MIPI CSI-2 or parallel Sub-LVDS serial data lanes, it secures pure, deterministic digital image routing loops and completely cuts off hardware synchronization delays.
- Full HD 1080p active matrix grid (2.13MP effective pixel count nodes for crisp surveillance video)
- Advanced MIPI CSI-2 and Sub-LVDS interface output delivering raw 10-bit/12-bit data streams safely
- Incredible fluid frame rates supporting up to 120 frames per second at full resolution cleanly
Key Performance Advantages
120fps High-Speed Capture
Captures full-resolution Full HD images at 120fps, delivering ultra-crisp fast-moving object tracking streams smoothly without motion blur or latency bottlenecks.
Sony STARVIS Technology
Exceeds the sensitivity limit of human eyes, pushing light acquisition into the near-infrared spectrum to secure clear colorful imaging in the dark safely.
Versatile Interface Support
Supports both MIPI CSI-2 and Sub-LVDS serial buses, ensuring seamless data interface communication with various mainstream DSPs and ISP processors smoothly.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Sony Semiconductor Solutions Corporation (Premium Sealed Allocation) |
| Part Number (MPN) | IMX290LQR (STARVIS High-Sensitivity Series) |
| Optical Format Size | 1/2.8-inch (Type 1/2.8, Approx. 6.46mm Diagonal) Active Layout |
| Resolution Density | 2.13 Megapixels (1945 x 1097 Effective Pixel Matrix Grid) |
| Pixel Size Dimensions | 2.9 µm × 2.9 µm Square Pixel Technology for High Dynamic Range |
| Data Interface Bus | MIPI CSI-2 (2-Lane / 4-Lane Modes) & Sub-LVDS (4-Ch / 8-Ch Modes) Serial Link |
| Output Format Modes | 10-bit / 12-bit Digital RAW Data Output Stream |
| Control Interface | I2C Standard 2-Wire Serial Communication Bus Link |
| Supply Voltages Nominal | Analog: 2.9V / Digital Core: 1.2V / Interface I/O: 1.8V Tri-Rail Layout |
| Component Package | Bare Silicon Die package (with Micro-Lens and Color Filter Arrays Integrated) |
Versatile Starlight Vision Applications
- Intelligent Security IP Cameras: Core sensor choice for top-tier low-light night-vision dome and bullet network cameras safely.
- Industrial Inspection Hubs: Delivers deterministic object counting, fast assembly line sorting, and automated robotics telemetry smoothly.
- Automotive Smart Driving Dash: Handles demanding vehicle lane positioning, optical obstacle identification, and night-vision tracking cleanly.
- Embedded AI Vision Nodes: Optimizes computational recognition parameters inside compact edge AI systems and professional biometric gates.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
