MAX232CSE+T RS-232 Transceiver
Dual-Drive/Receiver Architecture with On-Chip Charge Pump – The Ideal Choice for Professional Narrow-Body SOIC-16 Serial Level-Shifting Transceivers.
// High-Reliability Dual RS-232 Line Driver & Receiver Portfolio
The Industry-Standard Level Shifting Edge
The MAX232CSE+T represents a premier flagship interface solution for space-constrained, low-power layouts demanding robust RS-232 serial telemetry links. Engineered by Maxim Integrated, this dual line transceiver eliminates the need for bipolar ±12V power rails by utilizing an advanced on-chip charge-pump network. Running flawlessly off a single +5V supply rail, it provides deterministic bidirectional translation pathways between TTL/CMOS logic and RS-232 signal spectrums inside a compact 16-pin SOIC layout framework.
- Dual-channel transmitter & receiver layout supporting independent full-duplex lines
- Internal capacitive charge pumps generating full EIA/TIA-232 voltage levels
- Input hysteresis circuitry providing exceptional noise rejection across long serial connections
Key Performance Advantages
Single +5V Power Supply
Utilizes four external low-cost 1.0 µF capacitors to step up voltages natively, removing complex auxiliary dual-rail power supplies from the board.
120kbps Data Throughput
Guarantees clean serial communication baud rates over industrial cable lengths, fully meeting standard diagnostic bus interface specifications.
Narrow SOIC-16 Package
Housed in a narrow surface-mount package, optimizing real estate density and enabling seamless pick-and-place automation lines.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | Maxim Integrated / Analog Devices |
| Part Number (MPN) | MAX232CSE+T |
| Product Category | RS-232 Line Driver & Receiver 收发器芯片 |
| Configuration Array | 2 Independent Drivers / 2 Independent Receivers (Dual Full-Duplex) |
| Data Link Rate Max | 120 kbps (Typical Serial Transmission Boundary) |
| Operating Core Voltage | DC +4.5V to +5.5V Single Nominal Supply Rail |
| External Capacitor Size | 4 x 1.0 µF Standard Polarized/Ceramic Matrix |
| Package / Case Form | SOIC-16 Narrow / SO16 (0.150″, 3.90mm Width, Tape & Reel “+T”) |
| Receiver Hysteresis | 500 mV (Excellent EMI/Cross-Talk Squelch) |
| Temperature Window | 0°C to +70°C Standard Commercial Operating Spectrum |
Versatile Interface Applications
- Industrial COm Ports: Provides secure電平转换 linking microcontrollers (MCUs) to industrial computer serial communication matrices.
- Embedded Diagnostics Mainboards: Standard core debugging links, console interfaces, and local telemetry logging access ports.
- Networking & Modems: Manages clean data routing setups for legacy telecom routers, network hubs, and serial switches.
- Peripherals Isolation: Acts as an intermediate buffer protecting delicate logic microprocessors against external ESD cable strikes.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
