XC6SLX16-2FTG256C Spartan-6 FPGA
Expanded Logic Density meets Power Minimization – The Professional Spartan-6 LX16 FPGA Choice for Advanced Signal Bridging & High-Speed Logic Processing.
// High-Efficiency 14.5K Logic Cells Programmable Fabric Portfolio
The Spartan-6 LX16 Architecture Advantage
The XC6SLX16-2FTG256C represents a premier flagship solution for logic-intensive embedded engineering systems requiring extensive peripheral integration and tight power optimization. Engineered by AMD Xilinx on a mature, low-power 45-nm silicon process fabric, this Spartan-6 LX FPGA steps up your board capacity with 14,579 flexible logic cells paired alongside a 576 Kbits internal block RAM pool. Housed in a compact, low-inductive FTGB256 footprint, it secures massive parallel data throughput across 186 user-configurable I/O ports, successfully eliminating data bottlenecks in communication routing networks and industrial mainboards.
- 14,579 High-efficiency Logic Cells for robust hardware partitioning
- 186 Configurable User I/O pins optimized for independent multi-voltage rail drive
- Integrated digital clock managers (DCMs) and phase-locked loops (PLLs) ensuring absolute timing sync
Key Performance Advantages
Advanced Power Efficiency
Built on a low-power 45-nm dual-oxide process node, minimizing static and dynamic power drain while effectively capping localized logic board heat generation.
576Kb Block RAM Matrix
Houses dense integrated memory blocks that allow smooth dual-port FIFO data buffering, custom parameters caching, and deterministic execution speeds.
Massive 186 User I/O
Expands external interface capabilities with 186 user-configurable I/O pins, backed by multi-frequency global clock loops to stabilize wide bus interactions.
Technical Specifications
| Parameter Node | Detailed Engineering Specification |
|---|---|
| Manufacturer | AMD Xilinx |
| Part Number (MPN) | XC6SLX16-2FTG256C |
| Device Family | Spartan-6 LX FPGA Architecture Series |
| Logic Cells / Elements | 14,579 Logic Elements |
| Total Embedded RAM | 576 Kbits (576 KB Internal Block RAM Matrix) |
| Number of LABs / CLBs | 1,139 Logic Array Blocks |
| Number of User I/Os | 186 Configurable User I/O Ports |
| Package / Case Form | FTBGA-256 / FTG256 Footprint (Fine-Pitch Ball Grid Array Package, 17mm x 17mm) |
| Speed Grade Designation | -2 Speed Optimization Grade |
| Temperature Window | 0°C to +85°C Commercial Operational Spectrum Compliance |
Versatile Hardware Applications
- Industrial Automation: Runs real-time motor synchronization loops, sensor hub data harvesting, and automated PLC modules.
- High-Speed Interface Bridging: Ideal for custom PCIe expansions, micro-display deserializers, and video format conversions.
- Telecommunications Workstations: Handles clean packet data framing, serial protocol conversions, and peripheral multiplexing lines.
- System Logic Consolidation: Cleanly integrates discrete microcontrollers and hardware logic blocks onto a single secure platform.
Industrial Quality Protections
100% Original Sourcing: Procured securely through fully audited tier-1 franchise lines, completely ensuring anti-counterfeit protection.
Anti-Static Handling: Stored and picked in full alignment with international ANSI/ESD cleanroom facility benchmarks.
Full Batch Traceability: Verified via intensive certificate analysis and rigorous documentation tracking prior to export dispatch.
