C8051F120-GQR (100 MHz 8-Bit Mixed-Signal Microcontroller)

Silicon Labs 8051-compatible MCU with 128 kB Flash, 8,448 bytes RAM and up to 100 MIPS. 100-pin TQFP; 12-bit SAR, up to 100 ksps. Send the full code, quantity and programming needs for an RFQ.

SKU: C8051F120-GQR Category: Brand:

Mixed-signal control with C8051F120

C8051F120-GQR is an 8051-compatible mixed-signal microcontroller with 128 kB Flash, 8,448 bytes of RAM and up to 100 MIPS peak throughput. Its main ADC is 12-bit sar, up to 100 ksps, allowing firmware to combine measurement and control in one device.

The F120 combines a 16 × 16 multiply-accumulate engine with 64 digital I/O. Its 100-pin footprint and I/O allocation differ from the 64-pin F121.

Technical specifications

Specifications are summarized from the manufacturer documents linked below. Use the complete ordering code and the applicable datasheet revision when validating a design.

Manufacturer Silicon Labs
Ordering code C8051F120-GQR
Core CIP-51, 8051-compatible
Maximum clock / peak throughput 100 MHz / up to 100 MIPS; instruction-dependent
Flash / RAM 128 kB / 8,448 bytes
Digital I/O 64
ADC 12-bit SAR, up to 100 ksps; additional 8-bit ADC up to 500 ksps
DAC 2 × 12-bit DAC
Package 100-pin TQFP
Programming / debug JTAG
Supply versus clock 2.7–3.6 V up to 50 MHz; 3.0–3.6 V above 50 MHz; datasheet rail conditions apply
Operating temperature −40°C to +85°C

Applications

  • Measurement and control circuits where the 12-bit sar input path, reference and timing meet the signal requirements.
  • Maintenance of established equipment using an available, validated firmware image and the exact device pinout.

Selection and compatibility guide

Match the analog variant

The F120 combines a 16 × 16 multiply-accumulate engine with 64 digital I/O. Its 100-pin footprint and I/O allocation differ from the 64-pin F121. Confirm input range, reference, source impedance and conversion timing against the analog specification.

Check the board and firmware

Validate the 100-pin TQFP pin map, peripheral multiplexing, memory map and startup clock. Retain access to the JTAG programming/debug interface and the approved firmware image.

Review production continuity

Confirm the exact ordering suffix and lifecycle notice. A related 8051 MCU may require board changes, code changes and analog recalibration; accept a substitute only after validation.

Lifecycle and component sourcing

Include the full ordering code, silicon revision, required packing and any programming requirements in the RFQ. Confirm the offered condition, lot/date codes and available traceability before commercial approval.

  • Confirm the complete ordering code, lot/date-code restrictions and required packing.
  • Agree inspection scope, acceptance criteria and traceability documents for the offered lot.
  • Confirm availability, price and lead time in the quotation before ordering.

Request pricing and availability

Use Add to RFQ above for C8051F120-GQR and your quantity. Use Quick RFQ for a multi-part BOM.

  • Complete part number and required quantity
  • Target delivery date and destination
  • Packing, date-code, inspection and traceability requirements

Sending an RFQ does not place a paid order. Price, offered condition and delivery terms are confirmed in the quotation.
