Mixed-signal control with C8051F330
C8051F330-GMR is an 8051-compatible mixed-signal microcontroller with 8 kB Flash, 768 bytes of RAM and up to 25 MIPS peak throughput. Its main ADC is 10-bit sar, up to 200 ksps, allowing firmware to combine measurement and control in one device.
The F330 includes analog functions that are absent from some neighboring F33x variants. Its small memory budget and pin multiplexing require explicit firmware and peripheral allocation.
Technical specifications
Specifications are summarized from the manufacturer documents linked below. Use the complete ordering code and the applicable datasheet revision when validating a design.
| Manufacturer | Silicon Labs |
|---|---|
| Ordering code | C8051F330-GMR |
| Core | CIP-51, 8051-compatible |
| Maximum clock / peak throughput | 25 MHz / up to 25 MIPS; instruction-dependent |
| Flash / RAM | 8 kB / 768 bytes |
| Digital I/O | 17 |
| ADC | 10-bit SAR, up to 200 ksps |
| DAC | 1 × 10-bit current-output DAC |
| Package | 20-pin QFN |
| Programming / debug | C2 |
| Recommended supply | 2.7–3.6 V |
| Operating temperature | −40°C to +85°C |
Applications
- Measurement and control circuits where the 10-bit sar input path, reference and timing meet the signal requirements.
- Maintenance of established equipment using an available, validated firmware image and the exact device pinout.
Selection and compatibility guide
Match the analog variant
The F330 includes analog functions that are absent from some neighboring F33x variants. Its small memory budget and pin multiplexing require explicit firmware and peripheral allocation. Confirm input range, reference, source impedance and conversion timing against the analog specification.
Check the board and firmware
Validate the 20-pin QFN pin map, peripheral multiplexing, memory map and startup clock. Retain access to the C2 programming/debug interface and the approved firmware image.
Review production continuity
Confirm the exact ordering suffix and lifecycle notice. A related 8051 MCU may require board changes, code changes and analog recalibration; accept a substitute only after validation.
Lifecycle and component sourcing
Include the full ordering code, silicon revision, required packing and any programming requirements in the RFQ. Confirm the offered condition, lot/date codes and available traceability before commercial approval.
- Confirm the complete ordering code, lot/date-code restrictions and required packing.
- Agree inspection scope, acceptance criteria and traceability documents for the offered lot.
- Confirm availability, price and lead time in the quotation before ordering.
Request pricing and availability
Use Add to RFQ above for C8051F330-GMR and your quantity. Use Quick RFQ for a multi-part BOM.
- Complete part number and required quantity
- Target delivery date and destination
- Packing, date-code, inspection and traceability requirements
Sending an RFQ does not place a paid order. Price, offered condition and delivery terms are confirmed in the quotation.
