R5F100PGAFA#10 RL78/G13 General-Purpose Microcontroller
The R5F100PGAFA#10 is an RL78/G13 general-purpose 16-bit microcontroller for low-power embedded control. The ordering code corresponds to 128 KB code flash, 12 KB RAM, 8 KB data flash and a 100-pin LQFP package.
What R5F100PGAFA#10 Is Designed to Do
The R5F100PGAFA#10 is an RL78/G13 general-purpose 16-bit microcontroller for low-power embedded control. The ordering code corresponds to 128 KB code flash, 12 KB RAM, 8 KB data flash and a 100-pin LQFP package. Final suitability depends on the complete circuit, software, thermal, mechanical, qualification and lifecycle requirements.
For sourcing, the base family name is not enough. The full R5F100PGAFA#10 ordering code, package, packing format, revision or grade, source condition and required inspection evidence should be confirmed against the actual order.
- CPU: 16-bit RL78-S2
- Maximum frequency: 32 MHz
- Program memory: 128 KB flash
Key Selection Characteristics
CPU: 16-bit RL78-S2
This verified characteristic helps identify the intended device variant and should be reviewed together with the complete electrical, mechanical and lifecycle requirements.
Maximum frequency: 32 MHz
Use this performance point to confirm timing, throughput, interface compatibility and system-level margin before selecting the ordering code.
Program memory: 128 KB flash
This capacity or architecture detail helps determine whether the device fits the processing, storage, conversion or channel requirements of the target design.
Technical Specifications
| Parameter | Verified Identification Detail |
|---|---|
| Manufacturer | Renesas Electronics |
| Part Number (MPN) | R5F100PGAFA#10 |
| Component Type | RL78/G13 General-Purpose Microcontroller |
| CPU | 16-bit RL78-S2 |
| Maximum frequency | 32 MHz |
| Program memory | 128 KB flash |
| RAM | 12 KB |
| Data flash | 8 KB |
| Supply voltage | 1.6 V to 5.5 V |
| Package | 100-pin LQFP |
| Packing | Tray |
| Lifecycle / Status | Active family — exact ordering code review required |
Typical Application Directions
- Home and consumer appliances — review the complete interface, load, environment, qualification and lifecycle conditions for the target system.
- Industrial controllers — review the complete interface, load, environment, qualification and lifecycle conditions for the target system.
- Low-power general-purpose embedded systems — review the complete interface, load, environment, qualification and lifecycle conditions for the target system.
Order-Specific Procurement Review
Exact identity: Confirm the complete manufacturer part number, suffix, package, grade, packing format and acceptable alternatives.
Inspection evidence: Agree the required label, packaging, visual, traceability or additional test evidence before release.
Commercial and delivery terms: Review offered quantity, source condition, date or lot information, lead time, destination and shipping documents for the actual order.
Send R5F100PGAFA#10, quantity, target date, destination and evidence requirements.
Technical reference: manufacturer product page or datasheet.
Specifications support identification and sourcing review. Confirm the latest manufacturer documentation, complete ordering code and application requirements before design release or purchase.
