EFR32BG22C222F352GM40-CR

Silicon Labs Bluetooth Low Energy SoC with a 76.8 MHz Arm Cortex-M33, 352 kB Flash and 32 kB RAM. The EFR32BG22C222F352GM40-CR comes in a 5 × 5 mm QFN40 package with tape-and-reel packing for connected sensors, beacons and other compact wireless designs.

SKU: EFR32BG22C222F352GM40-CR Category: Brand:

Bluetooth LE connectivity for compact, battery-powered devices

The Silicon Labs EFR32BG22C222F352GM40-CR combines a 2.4 GHz radio and an Arm Cortex-M33 processor in one IC. It is a candidate for connected sensors, remote controls and Bluetooth beacons when the firmware, radio and board requirements fit its capabilities.

This is a wireless SoC, not a ready-to-use radio module. The final product still needs a suitable PCB, antenna and RF matching design, power supply and application firmware.

Technical specifications

Device-specific values checked against the Silicon Labs product page and EFR32BG22 datasheet. See the manufacturer documents for electrical conditions and limits.

Manufacturer Silicon Labs
Orderable part number EFR32BG22C222F352GM40-CR
Processor 32-bit Arm Cortex-M33; up to 76.8 MHz
Memory 352 kB Flash; 32 kB RAM
Wireless 2.4 GHz Bluetooth Low Energy; 1M and 2M PHY
Maximum transmit power +6 dBm
Receiver sensitivity −98.9 dBm at 1 Mbit/s GFSK, typical
General-purpose I/O 26 GPIO pins
Supply voltage 1.71–3.8 V
Temperature grade −40 to +85 °C
Package 40-pin QFN; 5 × 5 mm body
Revision and packing Revision C; tape and reel (R suffix)

Check these details before selecting the part

Match the Bluetooth features

The C222 variant does not support direction finding or LE Long Range. Silicon Labs also lists Bluetooth Mesh as unsupported for this device. Check the required Bluetooth features against the device and software stack before selecting it.

Keep the full ordering code

The GM40 package has 40 pins and 26 GPIOs. A 32-pin family member is not a direct footprint replacement. Confirm the complete suffix and packing with your BOM and assembly team.

Check firmware and board fit

Budget Flash and RAM for both the wireless stack and application. Validate antenna performance and power consumption on the finished board; transmit power alone does not establish range or battery life.

Request pricing and availability

Use Add to RFQ above to include this part and your quantity. For a multi-part requirement, use Quick RFQ to share your BOM.

  • Required quantity, target delivery date and destination
  • Reel or other packing needs, date-code or lot restrictions
  • Any inspection, traceability or documentation requirements

Price, availability, offered condition and lead time are confirmed in the quotation. Sending an RFQ does not place a paid order.
